Sandwich Panels Vacuum Suction Cups
Application: Ideal for lifting and installing corrugated roof panel, sandwich wall panels, and cooling room insulation panels
★ Lift capacity: 300kg
★ Suitable panel length: 10m/12m/14m/16m/20m
★ Control Mode: press buttons on the control panel, optional wireless remote control
★ Power source: Rechargeable battery power
Designed specifically for the installation of corrugated metal sheets, sandwich roof panels, and wall cladding, our vacuum lifter provides safe, efficient handling for construction and roofing projects.
Featuring long beam, adjustable suction pads, this vacuum lifter creates a secure grip on uneven, corrugated surfaces without damaging coatings or profiles. The lightweight yet robust aluminum frame allows easy maneuvering on-site, while the 360° rotation and tilt capability ensures precise positioning during installation. Equipped with a fail-safe vacuum system, pressure gauges, and safety alarms, it prevents accidental drops even if power is interrupted.
Ideal for lifting metal roofing, sandwich panels, and corrugated wall sheets, this tool drastically reduces manual labor, speeds up installation, and minimizes the risk of workplace injuries. It is compatible with cranes, hoists, and forklifts, making it a versatile solution for residential, commercial, and industrial construction sites.
| Model No. | Max Load capacity kg | Roof/Wall Panel Length mm | Suction Pads | Each Pad Size/Load | Beam Length mm | Extend Beam Qty | Manually Tilting | Wire Rope |
|---|---|---|---|---|---|---|---|---|
| SC-R2650 | 300 | 12,000 | 8 pcs | 110x530mm/75kg | 2650 | 2 | / | / |
| SC-W2650 | 300 | 12,000 | 8 pcs | 110x530mm/75kg | 2650 | 2 | Yes | / |
| SC-R4450 | 300 | 14,000 | 8 pcs | 110x530mm/75kg | 4450 | 4 | / | / |
| SC-W4450 | 300 | 14,000 | 8 pcs | 110x530mm/75kg | 4450 | 4 | Yes | / |
| SC-R4450L | 300 | 14,000 | 8 pcs | 110x530mm/75kg | 4450 | 4 | / | yes |
| SC-R6250 | 300 | 16,000 | 8 pcs | 110x530mm/75kg | 6250 | 6 | / | / |
| SC-W6250 | 300 | 16,000 | 8 pcs | 110x530mm/75kg | 6250 | 6 | Yes | / |
| SC-R6250L | 300 | 16,000 | 8 pcs | 110x530mm/75kg | 6250 | 6 | / | yes |
| SC-R8050L | 300 | 18,000 | 8 pcs | 110x530mm/75kg | 8050 | 8 | / | yes |
| SC-R9850L | 300 | 20,000 | 8 pcs | 110x530mm/75kg | 9850 | 10 | / | yes |
