Semi Electric Pallet Stacker
Application: material handling solution for warehouses, workshops and retail storage areas
★ Lift capacity: 1000kg /1500kg/2000kg
★ Lift height: 1.6m /2m/ 2.5m/3m/3.5m/4mm
★ Power source: Battery power for lifting and manually moving around
Our semi-electric stacker is a cost-effective and practical material handling solution for warehouses, workshops and retail storage areas. It features electric lifting and manual walking operation, balancing efficient stacking with flexible maneuverability in narrow spaces.
Equipped with a reliable battery system and sturdy mast structure, it ensures stable load lifting and long service life. The ergonomic design simplifies daily operation, reducing labor intensity and improving handling efficiency.
Lightweight, durable and easy to maintain, this semi-electric stacker is ideal for medium and low-level goods stacking, pallet loading and unloading, perfectly meeting daily lightweight logistics handling needs for small and medium enterprises.
| Model No. | Rated capacity kg | Lifting height m | Overall dimension mm | Net weight kg |
|---|---|---|---|---|
| SEM10-16 | 1000 | 1.6 | 1820*865*2060 | 350 |
| SEM10-20 | 1000 | 2 | 1810*865*1580 | 425 |
| SEM10-25 | 1000 | 2.5 | 1810*865*1830 | 450 |
| SEM10-30 | 1000 | 3 | 1810*930*2080 | 470 |
| SEM10-35 | 1000 | 3.5 | 1810*930*2330 | 500 |
| SEM15-25 | 1500 | 2.5 | 1810*865*1830 | 475 |
| SEM15-30 | 1500 | 3 | 1810*930*2080 | 495 |
| SEM15-35 | 1500 | 3.5 | 1810*930*2330 | 520 |
| SEM15-40 | 1500 | 4 | 1810*865*1580 | 470 |
| SEM20-16 | 2000 | 1.6 | 1820*865*2060 | 390 |
| SEM20-20 | 2000 | 2 | 1810*865*1580 | 470 |
